Screamin' Eagle Twin Cam Conversion Kit - 103CI to 110CI

Part Number: 92500031
Color: Black Highlighted
Qty
Only in stock
Only in stock for pickup

View Similar Items

Item is sold out but can be back ordered:

Learn More

Or be notified when back in stock.

Item is not available but can be preordered:

Learn More

Or be notified when back in stock.

Notify me when this item is available.
Item will be sold in-store only.
Add to Cart

Item Limit Error

Bring your Twin Cam motorcycle up to the same 110 cubic inch displacement and power output as the CVO Screamin' Eagle® models without expensive machining or removing the engine from the chassis. This street compliant kit combines the proven SE-255 cams and cylinder heads of the CVO model with exclusive Screamin' Eagle® bolt-on 4.0" cylinders and system-matched pistons to deliver high torque and reliable everyday performance.

...Read More
Screamin' Eagle Twin Cam Conversion Kit - 103CI to 110CI
Bring your Twin Cam motorcycle up to the same 110 cubic inch displacement and power output as the CVO Screamin' Eagle® models without expensive machining or removing the engine from the chassis. This street compliant kit combines the proven SE-255 cams and cylinder heads of the CVO model with exclusive Screamin' Eagle® bolt-on 4.0" cylinders and system-matched pistons to deliver high torque and reliable everyday performance.
Black highlighted
Automatic compression release-equipped cylinder heads and the flat top forged pistons combine to develop a 9.3:1 compression ratio for easy starting
Screamin' Eagle® lifters ensure quiet reliable valve train operation
Includes SE 4.0" bolt-on cylinders, CVO 110 cylinder heads, SE-255 cams, forged 9.3:1 compression pistons and rings, heavy duty clutch spring, top end and cam cover gaskets, and high-capacity roller tappets
Separate purchase of cam spacers is recommended and requires separate purchase of appropriate Automatic Compression Release Wiring Harness
All EFI-equipped models require dealer-installed ECM calibration download or use of Screamin' Eagle® Street Tuner Kit (priced separately)
Recalibration is required for proper installation, See Dealer for details, Labor cost not included
When installed by an authorized Harley-Davidson® Dealer at the time of vehicle delivery, these kits do not impact the vehicle's limited warranty

Fits ’10-'16 Touring models (except ’14-'16 models with Twin-Cooled engines). Does not fit Trike models, CVO 110 models, or models with engine cases that have been machined to accept large bore cylinders. Requires separate purchase of Screamin’ Eagle® high-flow air cleaner. ’10 FLHX and FLTRX models require separate purchase of 2-into-2 Head Pipe Kit and Mufflers. ’11-'16 Touring models require installation of CVO Mufflers P/N 64768-09A and 64769-09A or FatShotz Muffler Kit P/N 80847-10 (sold separately). ’10-11 Touring models require ACR Harness P/N 70623-08. Installation requires separate purchase of Primary Cover Gasket. Cam Drive Retention Kit P/N 25566-06.Cam Spacer Kit P/N 25928-06 is recommended. All models require ECM calibration for proper installation.

Dealer Install Recommended: Yes
ECM Calibration Required: Yes
Sold Separately: Click the Fitment tab above for details
Sold In Units: Each
Screamin' Eagle Stage Upgrade: Stage IV
In the Box: SE 4.0" bolt-on cylinders, CVO 110 cylinder heads, SE-255 cams, forged 9.3:1 compression pistons and rings, heavy duty clutch spring, top end and cam cover gaskets, and high-capacity roller tappets
WARRANTY: 1 year limited warranty – Go to www.h-d.com/warranty for full details
These Screamin’ Eagle® products are 50-State U.S. EPA compliant for sale and use on all applicable vehicles, including those that are pollution controlled. See Genuine Motor Parts and Accessories or Screamin’ Eagle Accessories catalog for fitment information. Screamin’ Eagle Performance products are intended for the experienced rider only.
